工作原理 Principle ：
两种互不相溶的流体以不低于0.8Mpa的压力进入分离器，流体沿着每根旋流管入口切向进入，在旋流管内高速旋转并向下推进，随着流道不断变窄，流体切向线速不断提升，最高可达100m/s并产生超过1500倍的重力加速度。由于两种介质存在密度差，就可以在2-3秒时间内轻相和重相的良好分离。
Fluid is fed into the hydrocyclone tangentially with above 0.8Mpa pressure. This creates a centrifugal movement, pushing the heavier phase outward and downward alongside the wall of the conical part. The decreasing diameter in the conical part increases the line speed up to 100m/s and creates 1500 G force , and so enhances the separation in 2-3 seconds. Finally, the heavier phased are discharged through the underflow outlet. The vortex finder in the overflow part creates a fast rotating upward spiral movement of the fluid in the center of the conically shaped housing, and the lighter phase is discharged through the overflow outlet.

产品特性 Feature：
根据每个项目的介质物性和分离要求定制化设计旋流管。Each liner of the specific project is tailor made to meet fluid physical property and separation requirement.
单台分离器最大处理能力可达500 m3/h 。Maximum capacity of each deoiler is up to 500 m3/h.
被分离的轻相物质，无论是液态还是固态，密度差需要超过5%,粒径超过20微米。The lighter phase can be liquid or solid, the density difference shall be above 5% and the drop size shall be above 20 micrometer.
流量大幅度变化下可采用多腔体设计，以可以满足分离效率稳定。Multiple champers design can handle the high flexibility.
旋流管材质为316L，双相钢，钛材，哈氏合金。Liner material include 316L, Duplex steel, Ti, Inconel.

客户获得的益处 Benefit：
极佳的抗堵性和耐腐蚀性 Best anti-fouling and anti-corrosion performance.
占地面积小，撬装发货，配管安装方便. Skid design, less footprint space and piping work.
无运动部件，连续运行不低于5年。No moving components, and the continuous operation time is over 5 years.

应用场合 Application：
除油或者不溶性液体 Remove liquid such as oil or insoluble liquid
除悬浮固体物 Remove suspended solids such as coke, catalyst.
